SPECIFICATIONS

Application: Wood Working Tool

Brand Name: LTOOLS

Choice: yes

DIY Supplies: Woodworking

Department: Unisex-adult

High-concerned chemical: None

Material: Plastic,Stainless steel

Model Number: Drawer rail assist device

Origin: Mainland China

Package: BOX

Pattern: Others

Product Category: Guide rail auxiliary device

Product Name: Drawer rail assist device

Scope of application: Woodworking tools

Size: As shown in the figure

Type: Combination

is_customized: No

semi_Choice: yes

Quick installation regulator
• Technical architecture:
Adopting a dual axis adjustment system, micro displacement accuracy is achieved through worm gear transmission
Support one handed operation of buckle locking
• Core components:
Aircraft aluminum body (6061-T6, hardness HV150)
Tungsten carbide wear-resistant coating (thickness 0.1mm, lifespan ≥ 10000 times)

Installation steps
•Step 1: Secure the base
•Step 2: Guide rail positioning
•Step 3: Lock the lock buckle
•Step 4: Accuracy testing

Daily maintenance standards
•Cleaning: Blow off sawdust with compressed air every 5 hours (pressure ≤ 0.3MPa)
• Lubrication: Apply NLGI grade 1 lithium molybdenum disulfide grease to the guide rail every month

Notes :
1. Manual measuring, please allow 1-3mm error,thank you.
2. Due to the difference between different monitors, the picture may not reflect the actual color of the item. We guarantee the style is the same as shown in the picture.
3.Due to long shipping, the item may damage in transit, if the item damage, pls contact us firstly immediately before leave feedback, thanks for your under.
