ZCUT-2 Automatic Electronic Tape Dispenser
The ZCUT-2 Automatic Electronic Tape Dispenser by BoYee is an electric-driven, semi-automatic adhesive tape cutting machine built from anti-static ABS. Designed for precision and productivity, it features a movable sensor to control turn table stopping positions and cut pieces, a bobbin-free design to accommodate any roll size, a mechanical lead screw for length settings, and adjustable tape spacing. It provides clean, consistent cuts with a 35W power rating, operating on 110V or 220V AC voltage.
Key Features
- Movable sensor for precise turn table stopping points and cut piece setting
- Bobbin-free configuration compatible with any roll size
- Knob-controlled adjustments for tape length and spacing
- Easy blade replacement requiring no adjustments
- Consistent tape lengths and clean, neat cuts to minimize waste
Specifications
- Model: ZCUT-2
- Brand: BoYee
- Body Material: Anti-Static ABS
- Driven Type: Electric
- Automatic Grade: Semi-Automatic
- Power: 35W
- Voltage: 110/220V AC
- Tape Width: 3-35 mm
- Cut Length: 12-60 mm
- Max Outside Diameter of Roller: 130 mm
- Accuracy of Cut: 1 mm (dependent on material)
- Length Setting: Mechanical (lead screw)
- Adjustable Tape Spacing: Yes
- Overall Dimensions: 256mm (L) x 130mm (W) x 165(H) mm (Source alternate specification dimension: 137 x 245 x 150mm)
- Core Components: PLC
- Packaging Compatibility: Cartons, paper materials
Applications and Buyer-Fit
The ZCUT-2 tape dispenser is engineered for machinery and hardware applications where efficient, semi-automatic adhesive tape dispensing and clean cutting are required. It suits operations seeking to standardize tape lengths, reduce material waste, and increase overall workspace productivity.
